Fluids Air & other gases, vapours & liquids compatible with the materials of construction.
Pressures -1 to +10 Bar
Temperatures -15 to +60°C dependant on o-ring and tube seal materials.
Materials Body – Brass | Stems – 1500 Derlin / 4500 316 Stainless Steel | Metering Orifice – PTFE | Springs – Stainless Steel
Ordering Code
Connector Size
Tube OD
1/8in R
3/16in A
1/4in B
4mm 004
5mm 005
6mm 006
O-Ring Material
Nitrile NE
Viton VN
Type Designation
Control
Panel 1500
Stud 1510
Metering
Panel 4500
Stud 4510
Example 1500 NE B
