Fluids Air & other gases, vapours & liquids compatible with the materials of construction.
Pressures -1 to +10 Bar
Temperatures +15 to +80°C dependant on o-ring and tube seal materials.
Materials Body – Brass | Stems – Delrin | Springs – Stainless Steel
Connector Size
Tube OD
3/16in R
1/4in A
5/16in B
6mm 005
8mm 006
O-Ring Material
Nitrile NE
Viton VN
Type designation
Union
Stud
2500
2510
Example 2500 NE B
